1 Set Dental 3D Intraoral Scaner S3 Digital CAD/CAM 9.6s Scanning Time
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | Bomaoer |
| MPN | Does not apply |
| Intended Use/Discipline | Dental Laboratory |
| Country/Region Of Manufacture | China |
| Unit Type | Unit |
1 Set Dental 3D Intraoral Scaner S3 Digital CAD/CAM 9.6s Scanning Time Technical Specification 1. Scanner Technical Specification Scope of reconstruction: 14 x 14 x 15 mm Camera resolution: 1.3MP CMOS Pixel size: 4.8μm Oral scanning light source: LED (without laser radiation) Export development data format: OBJ/STL/PLY Light radiant intensity:≤100Mw/cm2 Size of scanner handpiece: 200 × 58 × 36mm Scanner weight: 210g Data cable of Scanner (connecting USB control box to Scanner Handpiece): 2.0m USB control box cable (USB control box to computer connection):0.9m USB Connection: USB 3.0 or above 2. Equipment Operating Environment: a) Environment temperature:10℃-40℃ b) Relative humidity:≤85%; c) Atmospheric pressure:86KPa~106KPa; 3. Equipment Storage, Transportation Environment: a) Environment temperature:-20℃--55℃ b) Relative humidity:10%~93%; c) Atmospheric pressure:86KPa~106KPa; 4. Power Power adaptor Input power: 100-240V~50/60Hz500mA Out put power: 18VA Components Scanner handpiece, scanner tip, base, power adapter, USB control box, data cable, and U disk with software. Intended Use Using optical scanning method to collect the 3D geometric data of the tooth in the patients mouth and provide the 3D digital model for CAD/CAM denture design and processing. Intended User The scanner should be operated by a healthcare professional educated and competent to perform dental intraoral image acquisition. Power Power Adaptor Input: 100-240V~|50-60Hz| 0.5A Output: 12V --1.5A Intraoral scanner: 12V1.5A Product Life: 12 years Contraindication: No Total: 1 Set
